OMAX 40X-2000X Lab Trinocular Compound LED Microscope with 1.3MP Camera
View AllClose
- Total magnification: 40X-80X-100X-200X-400X-800X-1000X-2000X; Eyepieces: wide field WF10X and WF20X; Objective: achromatic DIN 4X, 10X, 40X(S), 100X(S, Oil); Viewing head: 45 degrees inclined 360 degrees swiveling trinocular; Sliding adjustable interpupillary distance: 2-3/16inch ~ 2-15/16inch(55mm ~ 75mm)
- Ocular diopter adjustable on both eyetubes; Nosepiece: revolving quadruple; Stage: mechanical double layer size: 4-1/2inchx 4-15/16inch (115mm x 125mm); Stage x-y stroke (travel range): 2-13/16inch x 1-3/16inch (70mm x 30mm); Condenser and diaphragm: NA1.25 Abbe condenser with iris diaphragm
- Transmitted (lower) illuminator: LED light, intensity adjustable; Focus adjustment: Coaxial coarse and fine knobs on both sides; All metal mechanical components; Power supply: AC/DC adapter, 100V-240V (UL approved)
- Digital camera: - True color 1280x1024 pixels (1.3MP) - Frame speed: 15fps at 1280x1024, 26fps at 640x512, 50fps at 320x256 - Software compatible with Windows and Mac OS X operating systems - Offers capturing still images, stitching, EDF, video recording and measurement functions - USB2.0 cable included
- 5-year warranty against manufacturing defects
